| Capacity | Up to 44 samples per run |
|---|
| Power | Universal input 100-240V / 50-60Hz |
|---|
| Sample ID | Integrated barcode reader |
|---|
| Carousel for 48 primary tubes | Tube size ranging from 12 mm to 17 mm |
|---|
| Integrated Industrial PC | For connection to LIS and interpretation software |
|---|
| Piston Pump | Volume range 10 µl to 2.5 ml |
|---|
| Peristaltic Pumps | Aspiration and reagent addition |
|---|
| Liquid Level Detection | Pressure sensing technology for samples and reagents |
|---|
| Integrated Camera | Integral camera for image capture of developed strips |
|---|
| Disposable Tips | 1 ml and 5 ml disposable tips can be used during the assay |
|---|
| Operator Interface | Integrated touch screen |
|---|
| Footprint | Less than 1000 mm width x 600 mm depth x 650 mm height |
|---|
